Ø 63

Popis produktu

Kód:	Ø 63
Výrobce:	Camozzi sro.
Ceny:	jsou uvedeny dole na stránce v tabulce variant produktu, nebo na poptávku přes formulář níže.
Termín dodání:	běžně cca 7 až 10 dnů od objednání, v závislosti na množství a aktuálních zásobách. Konkrétní termíny dodání ověřujeme a potvrzujeme emailem, individuálně dle zakázky. V případě nedostupnosti zboží lze objednávku zrušit. Více informací.

zavřít

3D modely

JMÉNO:
E-MAIL:
WWW:
TEXT:

Díl – objednací číslo: Ø 63 | Ø 63
Formát 3D:

Specifikujte prosím do pole níže konkrétní objednací kód, ke kterému žádáte zaslat 3D model nebo si jej stáhněte z tabulky dostupných variant v dolní části stránky produktu a to tlačítkem 3D nebo Stáhnout.

Objednací kód: Firma: Jméno: Příjmení: E-mail: Telefon: Text:

Vážení zákazníci, informujeme vás v souladu s nařízením EU, že poskytnuté informace nejsou námi dále nijak používány ani uschovány a slouží pouze pro vyřízení této žádosti. Více informací ZDE.

zavřít

Ke stažení

Catalogue

Detail zavřít

Zruš filtr
Objednací kód	Základní cena bez DPH	Objednat	Stroke (Length (mm))	Operation	Diameter (Length (mm))	Type	Magnetic	Rod seal	Version		CAD
6PF3P063RL0050	na dotaz	Poptat cenu	50	double-acting	63	Profile cylinders	Yes	NBR	standard	Detail	3D
6PF3P063RL0050G	na dotaz	Poptat cenu	50	double-acting	63	Profile cylinders	Yes	NBR	with brass rod scraper	Detail	3D
6PF3P063RL0050L	na dotaz	Poptat cenu	50	double-acting	63	Profile cylinders	Yes	without rod seal	standard	Detail	3D
6PF3P063RL0050P	na dotaz	Poptat cenu	50	double-acting	63	Profile cylinders	Yes	PU	standard	Detail	3D
6PF3P063RL0050V	na dotaz	Poptat cenu	50	double-acting	63	Profile cylinders	Yes	FKM	standard	Detail	3D
6PF3P063RL0100	na dotaz	Poptat cenu	100	double-acting	63	Profile cylinders	Yes	NBR	standard	Detail	3D
6PF3P063RL0100G	na dotaz	Poptat cenu	100	double-acting	63	Profile cylinders	Yes	NBR	with brass rod scraper	Detail	3D
6PF3P063RL0100L	na dotaz	Poptat cenu	100	double-acting	63	Profile cylinders	Yes	without rod seal	standard	Detail	3D
6PF3P063RL0100P	na dotaz	Poptat cenu	100	double-acting	63	Profile cylinders	Yes	PU	standard	Detail	3D
6PF3P063RL0100V	na dotaz	Poptat cenu	100	double-acting	63	Profile cylinders	Yes	FKM	standard	Detail	3D
6PF3P063RL0150	na dotaz	Poptat cenu	150	double-acting	63	Profile cylinders	Yes	NBR	standard	Detail	3D
6PF3P063RL0150G	na dotaz	Poptat cenu	150	double-acting	63	Profile cylinders	Yes	NBR	with brass rod scraper	Detail	3D
6PF3P063RL0150L	na dotaz	Poptat cenu	150	double-acting	63	Profile cylinders	Yes	without rod seal	standard	Detail	3D
6PF3P063RL0150P	na dotaz	Poptat cenu	150	double-acting	63	Profile cylinders	Yes	PU	standard	Detail	3D
6PF3P063RL0150V	na dotaz	Poptat cenu	150	double-acting	63	Profile cylinders	Yes	FKM	standard	Detail	3D
Objednací kód	Základní cena bez DPH	Objednat	Stroke (Length (mm))	Operation	Diameter (Length (mm))	Type	Magnetic	Rod seal	Version		CAD
6PF3P063RL0200	na dotaz	Poptat cenu	200	double-acting	63	Profile cylinders	Yes	NBR	standard	Detail	3D
6PF3P063RL0200G	na dotaz	Poptat cenu	200	double-acting	63	Profile cylinders	Yes	NBR	with brass rod scraper	Detail	3D
6PF3P063RL0200L	na dotaz	Poptat cenu	200	double-acting	63	Profile cylinders	Yes	without rod seal	standard	Detail	3D
6PF3P063RL0200P	na dotaz	Poptat cenu	200	double-acting	63	Profile cylinders	Yes	PU	standard	Detail	3D
6PF3P063RL0200V	na dotaz	Poptat cenu	200	double-acting	63	Profile cylinders	Yes	FKM	standard	Detail	3D
6PF3P063RL0250	na dotaz	Poptat cenu	250	double-acting	63	Profile cylinders	Yes	NBR	standard	Detail	3D
6PF3P063RL0250G	na dotaz	Poptat cenu	250	double-acting	63	Profile cylinders	Yes	NBR	with brass rod scraper	Detail	3D
6PF3P063RL0250L	na dotaz	Poptat cenu	250	double-acting	63	Profile cylinders	Yes	without rod seal	standard	Detail	3D
6PF3P063RL0250P	na dotaz	Poptat cenu	250	double-acting	63	Profile cylinders	Yes	PU	standard	Detail	3D
6PF3P063RL0250V	na dotaz	Poptat cenu	250	double-acting	63	Profile cylinders	Yes	FKM	standard	Detail	3D
6PF3P063RL0300	na dotaz	Poptat cenu	300	double-acting	63	Profile cylinders	Yes	NBR	standard	Detail	3D
6PF3P063RL0300G	na dotaz	Poptat cenu	300	double-acting	63	Profile cylinders	Yes	NBR	with brass rod scraper	Detail	3D
6PF3P063RL0300L	na dotaz	Poptat cenu	300	double-acting	63	Profile cylinders	Yes	without rod seal	standard	Detail	3D
6PF3P063RL0300P	na dotaz	Poptat cenu	300	double-acting	63	Profile cylinders	Yes	PU	standard	Detail	3D
6PF3P063RL0300V	na dotaz	Poptat cenu	300	double-acting	63	Profile cylinders	Yes	FKM	standard	Detail	3D
Objednací kód	Základní cena bez DPH	Objednat	Stroke (Length (mm))	Operation	Diameter (Length (mm))	Type	Magnetic	Rod seal	Version		CAD
6PF3P063RL0350	na dotaz	Poptat cenu	350	double-acting	63	Profile cylinders	Yes	NBR	standard	Detail	3D
6PF3P063RL0350G	na dotaz	Poptat cenu	350	double-acting	63	Profile cylinders	Yes	NBR	with brass rod scraper	Detail	3D
6PF3P063RL0350L	na dotaz	Poptat cenu	350	double-acting	63	Profile cylinders	Yes	without rod seal	standard	Detail	3D
6PF3P063RL0350P	na dotaz	Poptat cenu	350	double-acting	63	Profile cylinders	Yes	PU	standard	Detail	3D
6PF3P063RL0350V	na dotaz	Poptat cenu	350	double-acting	63	Profile cylinders	Yes	FKM	standard	Detail	3D
6PF3P063RL0400	na dotaz	Poptat cenu	400	double-acting	63	Profile cylinders	Yes	NBR	standard	Detail	3D
6PF3P063RL0400G	na dotaz	Poptat cenu	400	double-acting	63	Profile cylinders	Yes	NBR	with brass rod scraper	Detail	3D
6PF3P063RL0400L	na dotaz	Poptat cenu	400	double-acting	63	Profile cylinders	Yes	without rod seal	standard	Detail	3D
6PF3P063RL0400P	na dotaz	Poptat cenu	400	double-acting	63	Profile cylinders	Yes	PU	standard	Detail	3D
6PF3P063RL0400V	na dotaz	Poptat cenu	400	double-acting	63	Profile cylinders	Yes	FKM	standard	Detail	3D
6PF3P063RL0450	na dotaz	Poptat cenu	450	double-acting	63	Profile cylinders	Yes	NBR	standard	Detail	3D
6PF3P063RL0450G	na dotaz	Poptat cenu	450	double-acting	63	Profile cylinders	Yes	NBR	with brass rod scraper	Detail	3D
6PF3P063RL0450L	na dotaz	Poptat cenu	450	double-acting	63	Profile cylinders	Yes	without rod seal	standard	Detail	3D
6PF3P063RL0450P	na dotaz	Poptat cenu	450	double-acting	63	Profile cylinders	Yes	PU	standard	Detail	3D
6PF3P063RL0450V	na dotaz	Poptat cenu	450	double-acting	63	Profile cylinders	Yes	FKM	standard	Detail	3D
Objednací kód	Základní cena bez DPH	Objednat	Stroke (Length (mm))	Operation	Diameter (Length (mm))	Type	Magnetic	Rod seal	Version		CAD
6PF3P063RL0500	na dotaz	Poptat cenu	500	double-acting	63	Profile cylinders	Yes	NBR	standard	Detail	3D
6PF3P063RL0500G	na dotaz	Poptat cenu	500	double-acting	63	Profile cylinders	Yes	NBR	with brass rod scraper	Detail	3D
6PF3P063RL0500L	na dotaz	Poptat cenu	500	double-acting	63	Profile cylinders	Yes	without rod seal	standard	Detail	3D
6PF3P063RL0500P	na dotaz	Poptat cenu	500	double-acting	63	Profile cylinders	Yes	PU	standard	Detail	3D
6PF3P063RL0500V	na dotaz	Poptat cenu	500	double-acting	63	Profile cylinders	Yes	FKM	standard	Detail	3D
Uvedené ceny jsou základní při odběru od 1 ks. V případě většího množství Vám vypracujeme individuální cenovou nabídku.
