Ø 320

Popis produktu

Kód:	Ø 320
Výrobce:	Camozzi sro.
Ceny:	jsou uvedeny dole na stránce v tabulce variant produktu, nebo na poptávku přes formulář níže.
Termín dodání:	běžně cca 7 až 10 dnů od objednání, v závislosti na množství a aktuálních zásobách. Konkrétní termíny dodání ověřujeme a potvrzujeme emailem, individuálně dle zakázky. V případě nedostupnosti zboží lze objednávku zrušit. Více informací.

zavřít

3D modely

JMÉNO:
E-MAIL:
WWW:
TEXT:

Díl – objednací číslo: Ø 320 | Ø 320
Formát 3D:

Specifikujte prosím do pole níže konkrétní objednací kód, ke kterému žádáte zaslat 3D model nebo si jej stáhněte z tabulky dostupných variant v dolní části stránky produktu a to tlačítkem 3D nebo Stáhnout.

Objednací kód: Firma: Jméno: Příjmení: E-mail: Telefon: Text:

Vážení zákazníci, informujeme vás v souladu s nařízením EU, že poskytnuté informace nejsou námi dále nijak používány ani uschovány a slouží pouze pro vyřízení této žádosti. Více informací ZDE.

zavřít

Ke stažení

Catalogue

Detail zavřít

Zruš filtr
Objednací kód	Základní cena bez DPH	Objednat	Type	Version	Magnetic	Operation	Diameter (Length (mm))	Stroke (Length (mm))	Rod seal		3D
40M2L320F0050	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	50	NBR	3D	Detail
40M2L320F0050V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	50	FKM	3D	Detail
40M2L320F0100	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	100	NBR	3D	Detail
40M2L320F0100V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	100	FKM	3D	Detail
40M2L320F0200	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	200	NBR	3D	Detail
40M2L320F0200V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	200	FKM	3D	Detail
40M2L320F0300	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	300	NBR	3D	Detail
40M2L320F0300V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	300	FKM	3D	Detail
40M2T320F0050	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	50	NBR	3D	Detail
40M2T320F0050V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	50	FKM	3D	Detail
40M2T320F0100	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	100	NBR	3D	Detail
40M2T320F0100V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	100	FKM	3D	Detail
40M2T320F0200	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	200	NBR	3D	Detail
40M2T320F0200V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	200	FKM	3D	Detail
40M2T320F0300	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	300	NBR	3D	Detail
Objednací kód	Základní cena bez DPH	Objednat	Type	Version	Magnetic	Operation	Diameter (Length (mm))	Stroke (Length (mm))	Rod seal		3D
40M2T320F0300V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	300	FKM	3D	Detail
40M3L320F0050	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	50	NBR	3D	Detail
40M3L320F0050V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	50	FKM	3D	Detail
40M3L320F0100	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	100	NBR	3D	Detail
40M3L320F0100V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	100	FKM	3D	Detail
40M3L320F0200	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	200	NBR	3D	Detail
40M3L320F0200V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	200	FKM	3D	Detail
40M3L320F0300	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	300	NBR	3D	Detail
40M3L320F0300V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	300	FKM	3D	Detail
40M3T320F0050	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	50	NBR	3D	Detail
40M3T320F0050V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	50	FKM	3D	Detail
40M3T320F0100	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	100	NBR	3D	Detail
40M3T320F0100V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	100	FKM	3D	Detail
40M3T320F0200	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	200	NBR	3D	Detail
40M3T320F0200V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	200	FKM	3D	Detail
Objednací kód	Základní cena bez DPH	Objednat	Type	Version	Magnetic	Operation	Diameter (Length (mm))	Stroke (Length (mm))	Rod seal		3D
40M3T320F0300	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	300	NBR	3D	Detail
40M3T320F0300V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	300	FKM	3D	Detail
40M4L320F0050	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	50	NBR	3D	Detail
40M4L320F0050V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	50	FKM	3D	Detail
40M4L320F0100	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	100	NBR	3D	Detail
40M4L320F0100V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	100	FKM	3D	Detail
40M4L320F0200	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	200	NBR	3D	Detail
40M4L320F0200V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	200	FKM	3D	Detail
40M4L320F0300	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	300	NBR	3D	Detail
40M4L320F0300V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	300	FKM	3D	Detail
40M4T320F0100	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	100	NBR	3D	Detail
40M4T320F0100V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	100	FKM	3D	Detail
40M4T320F0300	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	300	NBR	3D	Detail
40M4T320F0300V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	300	FKM	3D	Detail
40M5L320F0050	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	50	NBR	3D	Detail
Objednací kód	Základní cena bez DPH	Objednat	Type	Version	Magnetic	Operation	Diameter (Length (mm))	Stroke (Length (mm))	Rod seal		3D
40M5L320F0050V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	50	FKM	3D	Detail
40M5L320F0100	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	100	NBR	3D	Detail
40M5L320F0100V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	100	FKM	3D	Detail
40M5L320F0200	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	200	NBR	3D	Detail
40M5L320F0200V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	200	FKM	3D	Detail
40M5L320F0300	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	300	NBR	3D	Detail
40M5L320F0300V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	300	FKM	3D	Detail
40M5T320F0050	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	50	NBR	3D	Detail
40M5T320F0050V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	50	FKM	3D	Detail
40M5T320F0100	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	100	NBR	3D	Detail
40M5T320F0100V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	100	FKM	3D	Detail
40M5T320F0200	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	200	NBR	3D	Detail
40M5T320F0200V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	200	FKM	3D	Detail
40M5T320F0300	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	300	NBR	3D	Detail
40M5T320F0300V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	Yes	double-acting	320	300	FKM	3D	Detail
Uvedené ceny jsou základní při odběru od 1 ks. V případě většího množství Vám vypracujeme individuální cenovou nabídku.
