Ø 250

Popis produktu

Kód:	Ø 250
Výrobce:	Camozzi sro.
Ceny:	jsou uvedeny dole na stránce v tabulce variant produktu, nebo na poptávku přes formulář níže.
Termín dodání:	běžně cca 7 až 10 dnů od objednání, v závislosti na množství a aktuálních zásobách. Konkrétní termíny dodání ověřujeme a potvrzujeme emailem, individuálně dle zakázky. V případě nedostupnosti zboží lze objednávku zrušit. Více informací.

zavřít

3D modely

JMÉNO:
E-MAIL:
WWW:
TEXT:

Díl – objednací číslo: Ø 250 | Ø 250
Formát 3D:

Specifikujte prosím do pole níže konkrétní objednací kód, ke kterému žádáte zaslat 3D model nebo si jej stáhněte z tabulky dostupných variant v dolní části stránky produktu a to tlačítkem 3D nebo Stáhnout.

Objednací kód: Firma: Jméno: Příjmení: E-mail: Telefon: Text:

Vážení zákazníci, informujeme vás v souladu s nařízením EU, že poskytnuté informace nejsou námi dále nijak používány ani uschovány a slouží pouze pro vyřízení této žádosti. Více informací ZDE.

zavřít

Ke stažení

Catalogue

Detail zavřít

Zruš filtr
Objednací kód	Základní cena bez DPH	Objednat	Type	Version	Operation	Magnetic	Diameter (Length (mm))	Stroke (Length (mm))	Rod seal		CAD
40M2L250F0050	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	50	NBR	Detail	3D
40M2L250F0050V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting	Yes	250	50	FKM	Detail	3D
40M2L250F0075	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	75	NBR	Detail	3D
40M2L250F0080	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	80	NBR	Detail	3D
40M2L250F0100	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	100	NBR	Detail	3D
40M2L250F0100V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting	Yes	250	100	FKM	Detail	3D
40M2L250F0125	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	125	NBR	Detail	3D
40M2L250F0150	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	150	NBR	Detail	3D
40M2L250F0160	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	160	NBR	Detail	3D
40M2L250F0200	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	200	NBR	Detail	3D
40M2L250F0200V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting	Yes	250	200	FKM	Detail	3D
40M2L250F0250	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	250	NBR	Detail	3D
40M2L250F0300	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	300	NBR	Detail	3D
40M2L250F0300V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting	Yes	250	300	FKM	Detail	3D
40M2L250F0320	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	320	NBR	Detail	3D
Objednací kód	Základní cena bez DPH	Objednat	Type	Version	Operation	Magnetic	Diameter (Length (mm))	Stroke (Length (mm))	Rod seal		CAD
40M2L250F0400	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	400	NBR	Detail	3D
40M2L250F0500	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	500	NBR	Detail	3D
40M2T250F0050	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	50	NBR	Detail	3D
40M2T250F0050V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting	Yes	250	50	FKM	Detail	3D
40M2T250F0075	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	75	NBR	Detail	3D
40M2T250F0080	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	80	NBR	Detail	3D
40M2T250F0100	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	100	NBR	Detail	3D
40M2T250F0100V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting	Yes	250	100	FKM	Detail	3D
40M2T250F0125	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	125	NBR	Detail	3D
40M2T250F0150	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	150	NBR	Detail	3D
40M2T250F0160	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	160	NBR	Detail	3D
40M2T250F0200	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	200	NBR	Detail	3D
40M2T250F0200V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting	Yes	250	200	FKM	Detail	3D
40M2T250F0250	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	250	NBR	Detail	3D
40M2T250F0300	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	300	NBR	Detail	3D
Objednací kód	Základní cena bez DPH	Objednat	Type	Version	Operation	Magnetic	Diameter (Length (mm))	Stroke (Length (mm))	Rod seal		CAD
40M2T250F0300V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting	Yes	250	300	FKM	Detail	3D
40M2T250F0320	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	320	NBR	Detail	3D
40M2T250F0400	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	400	NBR	Detail	3D
40M2T250F0500	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	500	NBR	Detail	3D
40M3L250F0050	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	50	NBR	Detail	3D
40M3L250F0050V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting	Yes	250	50	FKM	Detail	3D
40M3L250F0075	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	75	NBR	Detail	3D
40M3L250F0080	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	80	NBR	Detail	3D
40M3L250F0100	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	100	NBR	Detail	3D
40M3L250F0100V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting	Yes	250	100	FKM	Detail	3D
40M3L250F0125	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	125	NBR	Detail	3D
40M3L250F0150	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	150	NBR	Detail	3D
40M3L250F0160	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	160	NBR	Detail	3D
40M3L250F0200	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	200	NBR	Detail	3D
40M3L250F0200V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting	Yes	250	200	FKM	Detail	3D
Objednací kód	Základní cena bez DPH	Objednat	Type	Version	Operation	Magnetic	Diameter (Length (mm))	Stroke (Length (mm))	Rod seal		CAD
40M3L250F0250	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	250	NBR	Detail	3D
40M3L250F0300	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	300	NBR	Detail	3D
40M3L250F0300V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting	Yes	250	300	FKM	Detail	3D
40M3L250F0320	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	320	NBR	Detail	3D
40M3L250F0400	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	400	NBR	Detail	3D
40M3L250F0500	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	500	NBR	Detail	3D
40M3T250F0050	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	50	NBR	Detail	3D
40M3T250F0050V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting	Yes	250	50	FKM	Detail	3D
40M3T250F0075	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	75	NBR	Detail	3D
40M3T250F0080	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	80	NBR	Detail	3D
40M3T250F0100	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	100	NBR	Detail	3D
40M3T250F0100V	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting	Yes	250	100	FKM	Detail	3D
40M3T250F0125	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	125	NBR	Detail	3D
40M3T250F0150	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	150	NBR	Detail	3D
40M3T250F0160	na dotaz	Poptat cenu	Tie-rods cylinders with centre trunnion	standard	double-acting		250	160	NBR	Detail	3D
Uvedené ceny jsou základní při odběru od 1 ks. V případě většího množství Vám vypracujeme individuální cenovou nabídku.
